Mastercool 90067-220-SV — Professional 2-Stage Vacuum Pump 178 lit/min with Solenoid Valve 1/2 HP

The Ultimate: Maximum Capacity with Elite Protection

The Mastercool 90067-220-SV represents the absolute pinnacle of professional vacuum pump design. Combining flagship 178 litres per minute capacity with solenoid valve protection and elite ball bearing construction, this is the ultimate choice for professionals who demand maximum performance, maximum protection, and maximum durability. When only the best will do, the 90067-SV delivers.

Solenoid Valve Protection: Critical for Flagship Capacity

The integrated solenoid valve automatically closes when the pump stops, preventing oil from flowing back into the A/C system during power failures, accidental shutdowns, or when switching off the pump. On the flagship 90067 with its massive 708ml oil reservoir, this protection is absolutely essential — a power failure without solenoid protection could push significant amounts of oil back into your system.

Why This Matters on the Flagship: The 90067 holds 708ml of oil — nearly 50% more than the 90065 and almost three times the 90063. A power failure on a pump this size without solenoid protection could contaminate an entire large commercial system, requiring complete refrigerant replacement and system flushing. The SV model eliminates this risk entirely.

Elite Ball Bearing Design for Maximum Durability

The 90067-220-SV features elite ball bearing construction throughout — the ultimate in durability and longevity. Ball bearings reduce friction, run significantly cooler, and last far longer than standard sleeve bearings. On a flagship pump designed for continuous professional use on large systems, this premium construction is essential for long-term reliability.

Maximum Capacity Two-Stage Performance

With 178 litres per minute displacement at 50Hz, the 90067-SV is the most powerful pump in the professional range. The robust 1/2 HP motor ensures quick, easy start-up even in cold conditions, whilst the two-stage design achieves 25 microns ultimate vacuum. Perfect for systems with 2.25 kg charge capacity and above.

Professional Features for Demanding Work

• Solenoid Valve — Automatic protection against oil backflow during power failures or shutdowns
• Elite Ball Bearing Design — Superior durability, reduced friction, extended service life
• Powerful 1/2 HP Motor — Quick cold start-up, sustained performance, heavy-duty reliability
• Manifold Isolation Valve — Isolates pump from system for leak testing
• Three Inlet Ports — 1/4" SAE, 3/8" SAE, and 1/2" ACME (for automotive R134a systems)
• Gas Ballast Valve — Helps prevent oil contamination from high moisture content
• Advanced Cooling System — High-volume fan and cooling fins maintain optimal temperature
• Large Oil Reservoir — 708ml capacity for extended service intervals
• Easy Maintenance — Removable vapour discharge/oil fill port and accessible drain valve
• Oil Level Monitoring — Large sight glass with max/min indicators
• Thermal Protection — Motor protection with on/off rocker switch
• Check Valve Protection — Prevents oil back-flow during normal operation

Premium Construction Throughout

• Refined Cartridge Machining — Improved surface finish extends pump life
• Expanded Internal Oil Path — Minimises friction and heat buildup
• Upgraded Seals — Ensures maximum vacuum performance down to 25 microns
• U.S. Designed and Tested — American engineering with proven reliability
• Heavy-Duty Construction — Built for continuous professional use

Built for Professional Excellence

• Robust Design — Easy-grip handle and reinforced base (17 kg)
• Professional Footprint — 41 x 15.5 x 27.5 cm dimensions
• 220V 50/60Hz Power — UK/European standard (Schuko cable)
• Multiple Connection Options — Manifold with 1/4" SAE, 3/8" SAE, and 1/2" ACME ports

Technical Specifications

• Stages: Two-stage
• Free Air Displacement: 178 lit/min (50 Hz), 213 lit/min (60 Hz)
• Ultimate Vacuum: 25 microns*
• Motor: 1/2 HP, 1425 RPM (50 Hz), 1725 RPM (60 Hz)
• Power: 220V, 50/60 Hz (Schuko cable)
• Weight: 17 kg (36.5 lbs)
• Dimensions: 41 x 15.5 x 27.5 cm
• Oil Capacity: 708 ml (24 oz)
• Connections: Manifold with 1/4" SAE, 3/8" SAE, 1/2" ACME ports
• System Capacity: 2.25 kg charge capacity and above
• Features: Solenoid valve, elite ball bearing design, 1/2 HP motor, manifold isolation valve, gas ballast valve, check valve, three inlet ports

Service Information

• Oil Capacity: 708 ml (24 oz)
• Replacement Cartridge: 90167-R
• Seal Service Kit: 90062-11-SEAL
• Recommended Oil: Mastercool vacuum pump oil (90024-6 or 90032-6)

When Only the Ultimate Will Do

The 90067-SV is the pump of choice when:

• Maximum Protection — Large commercial systems where contamination risk is unacceptable
• Unstable Power — Job sites with unreliable mains power or generator use
• Professional Reputation — Your business demands the absolute best equipment
• High-Value Systems — Premium installations requiring maximum reliability
• Continuous Use — High-volume operations requiring maximum durability
• Long-Term Investment — Elite ball bearing design for extended service life
• Peace of Mind — Automatic protection plus premium construction

The Ultimate Professional Choice

The 90067-220-SV is the pump you choose when compromise is not an option. With flagship 178 lit/min capacity, solenoid valve protection, elite ball bearing construction, and a powerful 1/2 HP motor, it represents the absolute pinnacle of professional vacuum pump design. This is the pump for serious professionals who work on large commercial systems and demand the ultimate in performance, protection, and durability.

Perfect for:

• Commercial HVAC contractors working on large systems requiring maximum protection
• Industrial refrigeration service and installation
• Supermarket and cold storage facility maintenance
• High-volume service operations with unstable power supply
• Premium commercial installations where contamination risk is unacceptable
• Professional workshops requiring flagship capacity with protection
• Technicians who demand the absolute best equipment available
• Businesses where reputation and reliability are paramount

The Ultimate Investment

The 90067-220-SV represents the ultimate investment in professional vacuum pump technology. The solenoid valve protects against contamination incidents that could cost thousands in materials, labour, and reputation damage. The elite ball bearing design extends pump life significantly, reducing long-term ownership costs. The 1/2 HP motor and 178 lit/min capacity save time on every job. This is the pump that pays for itself through protection, durability, and productivity.

*Note: Micron readings represent optimal laboratory conditions. Field conditions may vary.

Elite ball bearing design with solenoid valve protection. The ultimate professional vacuum pump. Technical documentation and parts lists available for download above.
