Mastercool 90067-220 Professional 2-Stage Vacuum Pump - 178 Litres/Min

Professional-grade 2-stage vacuum pump designed for demanding HVAC/R applications. Delivers exceptional performance with 178 litres per minute free air displacement and deep vacuum capability down to 25 microns. Ideal for medium to large commercial systems (5 lb capacity and above), automotive A/C, and professional refrigeration service. The 1/2 horsepower motor ensures quick and easy cold-temperature start-up. Built for reliability and speed in professional workshops and mobile service vehicles. 220V/50Hz European specification.

Key Features:

• High capacity: 178 litres/min free air displacement
• 2-stage rotary vane design
• Ultimate vacuum: 25 microns
• 1/2 HP motor for reliable performance
• 220V/50Hz operation
• 1425 RPM pump speed
• Three inlet ports: 1/4" FL, 3/8" FL, 1/2" ACME
• Manifold valve to isolate from the system
• Oil sight glass for easy monitoring
• Gas ballast valve for moisture removal
• Robust construction
• Professional-grade durability

Specifications:

• Model: 90067-220
• Stages: 2-stage rotary vane
• Free Air Displacement: 178 litres/min
• Ultimate Vacuum: 25 microns*
• Motor: 1/2 HP
• Pump Speed: 1425 RPM
• Voltage: 220V/50Hz
• Inlet Ports: 1/4" FL, 3/8" FL, 1/2" ACME
• Oil Capacity: 24 oz (708 ml)
• Dimensions: 41 x 15.5 x 27.5 x 24 cm
• Shipping Weight: 16 kg (35.5 lbs)
• Replacement Cartridge: 90167-R
• Seal Service Kit: 90062-11-SEAL

*Micron readings represent optimal laboratory conditions. Field conditions may vary.

Applications:

• Medium to large commercial A/C systems (5 lb+ capacity)
• Industrial refrigeration
• Automotive A/C service (R134a compatible)
• Heat pump installation
• Commercial refrigeration
• HVAC system evacuation
• Professional mobile service
• Workshop and garage use

Benefits:

Professional 2-stage design delivers superior vacuum depth and faster evacuation times compared to single-stage pumps. 178 litres/min capacity handles medium to large systems efficiently, reducing service time and improving productivity. The ultimate vacuum of 25 microns ensures the complete removal of moisture and non-condensable gases, which are critical for system longevity and optimal performance. The 1/2 HP motor provides reliable cold-weather start-up, essential for professional use. Three inlet ports (1/4" FL, 3/8" FL, 1/2" ACME) offer maximum flexibility - the 1/2" ACME port is specifically designed for automotive R134a systems. The manifold valve allows isolation from the system for convenient operation. The gas ballast valve enables effective moisture removal without contaminating the pump oil. The oil sight glass allows for quick visual oil level checks without stopping work. Robust construction withstands demanding professional use. Durable and time-tested Mastercool quality stands up to the most gruelling conditions and provides years of reliable service. Complete service parts are available, including the replacement cartridge (90167-R) and seal service kit (90062-11-SEAL).

Service Information:

• Oil Capacity: 24 oz (708 ml)
• Replacement Cartridge: 90167-R
• Seal Service Kit: 90062-11-SEAL

Professional 2-stage vacuum pump. 178 litres/min. Ultimate vacuum 25 microns. 1/2 HP motor. 220V/50Hz. Three inlet ports. Ideal for medium to large A/C systems and automotive service.
